Western Star 47 x

Name: Western Star 47 x - Truck Shop Dealer Auburn
SKU: 47 x

Category: X series Last Updated: 11/28/2025 05:52 PM

Manufacturer: WESTERN STAR

Request A Quote

Is this still available ?
Ask us a specific question !

Make & Model

Manufacturer:

WESTERN STAR

Model:

47 x

Additional Information

Series/Category:

X series

BBC:

111.6

Engine:

Detroit® DD13® Gen 5, 370-525 HP, 1,250-1,850 lb-ft Cummins L9, 260-380 HP, 860-1,250 lb-ft Cummins X12, 350-500 HP, 1450-1700 lb-ft

Transmission:

Detroit® DT12®-V AMT Allison 3000 and 4000 Series Automatics Eaton Fuller 10- 13- 18-speed; 8LL and 9ALL Manuals Eaton Ultrashift PLUS and Endurant AMT

Grille:

Radiator-mounted steel grille with stainless steel surround

Bumper:

Standard 1/8" stainless steel vocational Optional 3/16" painted steel Optional 1/4" plain or polished aluminum Optional 5/16" bright steel severe service Optional 3/8" painted steel severe service Optional 1/4" painted or bright steel logger

Air Intake:

Engine mounted air intake, plus optional hood-mounted pre-cleaner deliver improved dust capacity

HVAC:

Best-in-class HVAC with 5 face outlets, 4 floor outlets, 2 side window defrost outlets and 10 blower speeds Available only on sleepers, optional Idle-Free Dual HVAC that provides up to 10 hours of cooling or 34 hours of heating when parked

Front Axle:

Detroit® single 12,000-23,000 lbs Meritor single 12,000-22,000 lbs

Rear Axle:

Detroit® single 23,000 lbs Detroit® tandem 40,000-46,000 lbs Dana tandem 46,000-50,000 lbs Meritor single 21,000-30,000 lbs Meritor tandem 40,000-58,000 lbs Meritor tridem 69,000-78,000 lbs

Front Suspension:

Flatleaf 14,600-23,000 lbs Flatleaf (Tandem) 40,000 lbs Taperleaf 12,000-20,000 lbs Taperleaf (Tandem) 40,000 lbs

Rear Suspension:

AirLiner® single 21,000-23,000 lbs AirLiner® tandem 40,000-46,000 lbs AirLiner® tridem 69,000 lbs Chalmers tandem 40,000-70,000 lbs Flatleaf single 23,000-30,000 lbs Hendrickson tandem 40,000-70,000 lbs Neway single 26,000 lbs Neway tandem 46,000-52,000 lbs Neway tridem 69,000-78,000 lbs TufTrac tandem 40,000-52,000 lbs

Brakes:

WABCO® 4S/4M and 6S/6M Anti-lock Braking System (ABS) with and without traction enhancement Air Disc Brakes

Fuel Tanks:

Aluminum 25" cylindrical, plain or polished LH 60-150 gallon (227-568 liter) LH 60, 80 and 90 gallon rectangular tanks Optional raised fuel tank mounting RH 60-, 70-, 80-, 100-, 120-, 150-gallon (227-, 265-, 303-, 379-, 454-, 569-liter) Standard forward mounting; optional aft mounting LH and RH split fuel/hydraulic tank options available LH and/or RH auxiliary fuel supply and return ports available

Description

Our X-Series trucks aren’t just the best trucks we’ve ever built, they’re the best trucks anyone has ever built. Like the 49X before it, the 47X is part of a family that was built from the ground up to bring toughness into the modern age with an impressive collection of engineering, technology and more than half a century of experience building trucks that take on any challenge, anywhere.
